Product details of the blow molding machine factory

Quick Overview

Product Introduction

Technical data

CPXF Series (maximum bottle volume=3L, efficiency=95%, without quick changeover of molds)
Mainly suitable for: 2.5-3L large-diameter water bottles and juice bottles, and 2L bottles with handle applied after blowing
Serial number	Model	Number of cavities	Water bottle (≤1500ml)		CSD bottle (≤600ml)		Hot filling bottle （≤500ml, 92~82℃）		Mold shell	Maximum bottle size
Serial number	Model	Number of cavities	Output per mold	Output total	Output per mold	Output total	Output range		Mold shell	Maximum bottle size
1	CPXF04A	4	2000	8000	2000	8000	4000	8000	180x180	Φ130x350
2	CPXF06A	6	2000	12000	2000	12000	6000	12000
3	CPXF08A	8	2000	16000	2000	16000	8000	16000
4	CPXF10A	10	2000	20000	2000	20000	10000	20000
5	CPXF12A	12	2000	24000	2000	24000	12000	24000
6	CPXF14A	14	2000	28000	2000	28000	14000	28000
7	CPXF16A	16	2000	32000	2000	32000	16000	32000
8	CPXF18A	18	2000	36000	2000	36000	18000	36000
9	CPXF20A	20	2000	40000	2000	40000	20000	40000
10	CPXF22A	22	2000	44000	2000	44000	22000	44000
11	CPXF24A	24	2000	48000	2000	48000	24000	48000

Other series

The Square Cavity Series Is Mainly Suitable for Blowing Bottles Below 2.5L- TECH-LONG-1 3

Large cavity series

Small cavity series

Super cavity series

Standard cavity series
