CPXD series automatic rotary blow molding machine with large cavities is independently developed by TECH-LONG with the most advanced bottle-making technology, and it is mainly suitable for blowing bottles with the volume of 5-10L.CPXD series can be used to blow bottles independently, and can also be in block arrangement with filling machine and capping machine.
CPXD stands for super-large cavity rotary blow molding machine (suitable bottle volume is 5-10L). The maximum possible capacity of CPXD12 up to 14,400 BPH.
Technical Features
● Extremely high productivity: output of 1500 bottles/mold hour (5L).
● Complete with high-efficiency high-pressure gas recovery system for twice recovery, and the recovery efficiency is over 60%.
● Compared with the traditional oven, it saves energy by 35-45%.
● Excellent and stable product quality.
● High degree of automation and intelligence.
Technical data
CPXD series (4-10L, efficiency 95%, without quick changeover of molds) |
||||||||
Application: water, beverage, edible oil bottle, etc. |
||||||||
Serial number |
Model |
Number of cavities |
Water bottle, oil bottle (4-10L) |
Mold shell |
Maximum bottle size |
|||
4-6L |
8-10L |
|||||||
Output per mold |
Output total |
Output per mold |
Output total |
|||||
1 |
CPXD02 |
2 |
1200 |
2400 |
750 |
1500 |
290 |
Φ200x410 |
2 |
CPXD03 |
3 |
1200 |
3600 |
750 |
2250 |
||
3 |
CPXD04 |
4 |
1200 |
4800 |
750 |
3000 |
||
4 |
CPXD06 |
6 |
1200 |
7200 |
750 |
4500 |
||
5 |
CPXD08 |
8 |
1200 |
9600 |
750 |
6000 |
||
6 |
CPXD10 |
10 |
1200 |
12000 |
750 |
7500 |
||
7 |
CPXD12 |
12 |
1200 |
14400 |
750 |
9000 |
