Custom China Labeling Machine Suppliers

Aplikaj areoj

Aplika gamo

Botelmaterialo: PET, vitro kaj metalo;

Label materials: OPP, BOPP, composite film, paper labels, etc.;

Produkta tipo: water, beverage, home care and personal care, and other industries.

Formo de botelo: round bottle, rectangular bottle and oval bottle;

Kapacito de botelo:  0.2L to 15L and other common bottle types in the market;

● Small bottle series hot melt adhesive labeling machine;

● Large bottle series hot melt adhesive labeling machine;

● Cam curve mechanical positioning series hot melt adhesive labeling machine;

●   Full servo positioning series hot melt adhesive labeling machine.

● Simple operation and maintenance;

● Parts associated with different bottle types and labels can be replaced within 15 minutes;

● The adjustment process of moving and fixed cutting knives is simple, with excellent cutting performance and high service life;

● By optimizing the design of the structure, the number of wearing parts is reduced to the maximum extent, thereby improving its service life;

● By optimizing the design of label conveying mechanism and control system, the adaptability of labels is enhanced;

● The optimization design of glue supply system and glue rolling mechanism functions to enhance the adaptability of hot melt adhesive;

● By optimizing the adhesive drum assembly, the adhesive performance and issues such as glue throwing and wire drawing are improved, and the consumption of glue is indirectly reduced.

● By optimizing the movable platform and bottom drive, the noise and vibration of the equipment during high-speed labeling are reduced.

Working principle: A detection point is set on the conveying chain in the bottle feeding direction to automatically control the running speed (low, medium, high and stop) of the equipment. The bottle is conveyed to the rotary mechanism through the screw, and the equipment starts to run automatically after receiving the bottle feeding signal fed back by the detection device. After the label passes through the tensioning mechanism and the film guide, it enters the label cutting mechanism where it is severed into predetermined lengths. The labels, which have been cut to the desired length, are transferred to the labeling mechanism through vacuum adsorption, and the rotating labeling mechanism rotates around the glue rolling mechanism, and then, the labels with hot melt adhesive are stuck at both ends and attached to the bottles of the rotary mechanism. Finally the labeling process is completed after the bottle is leveled with the label by the label brush. At the same time, the running speed (stop or run) of the equipment is controlled through the detection point set by the bottle outfeed chain.

Karakterizaĵoj:

● Glue drum: laser engraving is adopted to accurately control the processing depth, thus greatly reducing the amount of rubber used by customers and saving costs for customers;

●  Automatic splicing: changing the label reel without stopping the machine to improve efficiency;

● Fume extraction device: use a fan to draw away the inevitable glue wire generated by hot melt adhesive heating, so as to protect the environment and the health of customers.
